Lift capacity: 3000lbs
Support capacity: 5000lbs
Includes swivel pipe that must be welded on. Pin and lanyard also included.
Grease zerk installed for easy maintenance.
Bracket height (center of swivel tube to bottom of jack tube): 15 1/2″ Retracted & 30″ Extended
Lift/stroke: 14 1/2″
Measurement from center of swivel tube to tallest point of jack: : 6 1/2″
Measurement from center of swivel tube to bottom of outer tube: 14 3/4″
Tube diameter: 2″ Inner & 2 1/4″ Outer
Handle winding radius: 8″
